TambourGuard Secure Storage Shutters

TambourGuard secure storage shutters provide top-tier protection for your business assets. When closed, the security roller shutters act as a reliable barrier, safeguarding your products, merchandise, equipment, and valuables from adverse weather conditions, vandalism, and theft. Crafted from corrosion-resistant, commercial-grade aluminum, these storage unit doors offer lightweight, resilient, and stylish protection.

TambourGuard helps businesses turn open shelving, records areas, equipment zones, and high-value inventory spaces into cleaner, more controlled storage environments. These storage unit roller doors support better organization, faster access, and dependable protection without taking up the swing space of traditional doors. With Pentagon, customers also gain access to custom sizing, practical design guidance, and experienced dealer support that helps each shutter fit the space and the way the business operates.

Whether you own a retail store, warehouse, or office space, we have the perfect solution for you. TambourGuard secure storage shutters come in various sizes, colors, and curtain designs to suit your specific business needs and aesthetic. You’ll also enjoy their simple operation and minimal maintenance.

EntrexGuard
DETAIL SHEET
COMMERCIAL

HOW DOES THE TAMBOURGUARD SHUTTER WORK?

Click On Each Part to Find Out More

SELECT A TAMBOURGUARD PART TO EXPLORE!

No part is selected.
Click on a part and find out more!

SELECT A TAMBOURGUARD PART TO EXPLORE!
Box Housing Operation Bottom Bar Guide Rails Operation Box Housing Bottom Bar Storage Unit Guide Rails Curtain

Box Housing

The box housing is constructed of roll formed aluminum, with a sleek and compact design. Varying sizes of box housings are used depending on the overall size of the shutter.

The box housing encloses the curtain when the shutter is in the open position. On motorized shutters, the motor is located inside the box housing, which rotates an axle to coil up the shutter's curtain inside the box. TambourGuard box housings have the most compact design in the industry due to our extensive engineering of the curtain to coil up into the smallest box possible.

The compact box housing feature is especially beneficial with the TambourGuard product line because the shutters are used for storage, and every little bit of space saved is valuable.

TambourGuard box housings are designed to be extremely accessible if maintenance or servicing are required.

The commercial grade aluminum is environmentally friendly, with a powder coated finishing. Box housings are available in a wide range of colors including 6 standard colors and any custom color to your specification.

DISCOVER MORE FEATURES AND COLOR OPTIONS

Operation

TambourGuard shutters offer multiple operation methods via remote, app, or Wi-Fi. Using world-leading motor brands, our shutters operate extremely quietly and smoothly. Options are available for both single-channel and multi-channel controls. Each channel is able to operate one shutter or a group of shutters making it extremely simple and efficient to control any number of shutters.

Remotes feature 3 main buttons including up and down operation, and a stop button. The remotes allow you to operate the shutter up and down by pressing the button once, and stop the shutter curtain at any position.

The app available makes operation of the shutter extremely convenient and can be done from anywhere, even when you are not present. This allows you to secure your storage units from any location!

The Wi-Fi option allows you to integrate shutter operation with your smart office automation.

DISCOVER MORE FEATURES

Bottom Bar

There are three bottom bar options for TambourGuard rolling shutters:

  • Standard 57 mm Bottom Bar
  • Standard 60 mm Bottom Bar

Each of these bottom bar options are used based on the curtain series being used and the strength required for your shutter. The bottom bars are constructed of extruded aluminum, with an attractive powder-coated finish with many color options. Multiple bottom bar locks are available to secure the shutter to the highest level.

DISCOVER MORE FEATURES

Guide Rails

There are seven guide rail options for TambourGuard storage shutters:

  • Standard 53 mm Guide Rail
  • Standard 64 mm Guide Rail
  • Standard 66 mm Guide Rail
  • Standard 83 mm Guide Rail
  • STAX 53 mm Guide Rail (Buildout)
  • STAX 66 mm Guide Rail (Buildout)
  • AnchorLoc 83 mm Guide Rail (End-Retention)

Standard Guide Rails provide immense strength with multiple size options used based on the curtain series needed.

STAX Guide Rails (buildout) provide the same strength as Standard Guide Rails with the addition of our STAX system. The STAX system allows you to build your shutter out from the storage unit or whatever surface your shutter is mounted to. This is very advantageous when you shutter needs to clear an object that would obstruct the path of the shutter curtain (an example of this is a drawer handle the shutter must clear).

AnchorLoc guide rails feature our end-retention system, providing an extreme level of strength for the shutter curtain, making it near-impossible to force the curtain out of the guide rails. This system consists on anchors that are attached to the curtain at regular intervals and fastened to the guide rails to prevent the curtain from potentially being forced out of the guide rails.

DISCOVER MORE FEATURES

Operation

TambourGuard shutters offer multiple operation methods via remote, app, or Wi-Fi. Using world-leading motor brands, our shutters operate extremely quietly and smoothly. Options are available for both single-channel and multi-channel controls. Each channel is able to operate one shutter or a group of shutters making it extremely simple and efficient to control any number of shutters.

Remotes feature 3 main buttons including up and down operation, and a stop button. The remotes allow you to operate the shutter up and down by pressing the button once, and stop the shutter curtain at any position.

The app available makes operation of the shutter extremely convenient and can be done from anywhere, even when you are not present. This allows you to secure your storage units from any location!

The Wi-Fi option allows you to integrate shutter operation with your smart office automation.

DISCOVER MORE FEATURES

Box Housing

The box housing is constructed of roll formed aluminum, with a sleek and compact design. Varying sizes of box housings are used depending on the overall size of the shutter.

The box housing encloses the curtain when the shutter is in the open position. On motorized shutters, the motor is located inside the box housing, which rotates an axle to coil up the shutter's curtain inside the box. TambourGuard box housings have the most compact design in the industry due to our extensive engineering of the curtain to coil up into the smallest box possible.

The compact box housing feature is especially beneficial with the TambourGuard product line because the shutters are used for storage, and every little bit of space saved is valuable.

TambourGuard box housings are designed to be extremely accessible if maintenance or servicing are required.

The commercial grade aluminum is environmentally friendly, with a powder coated finishing. Box housings are available in a wide range of colors including 6 standard colors and any custom color to your specification.

DISCOVER MORE FEATURES AND COLOR OPTIONS

Bottom Bar

There are three bottom bar options for TambourGuard rolling shutters:

  • Standard 57 mm Bottom Bar
  • Standard 60 mm Bottom Bar

Each of these bottom bar options are used based on the curtain series being used and the strength required for your shutter. The bottom bars are constructed of extruded aluminum, with an attractive powder-coated finish with many color options. Multiple bottom bar locks are available to secure the shutter to the highest level.

DISCOVER MORE FEATURES

Storage Unit

TambourGuard storage shutters are designed to be mounted to storage and shelving units. Our storage shutters can be mounted to any storage unit, old or new, including static storage units, high density mobile storage units, and high density bi-lateral storage units.

Pentagon does not provide the storage units, however out TambourGuard shutters can be installed on both new units and they can retrofitted onto existing units.

Guide Rails

There are seven guide rail options for TambourGuard storage shutters:

  • Standard 53 mm Guide Rail
  • Standard 64 mm Guide Rail
  • Standard 66 mm Guide Rail
  • Standard 83 mm Guide Rail
  • STAX 53 mm Guide Rail (Buildout)
  • STAX 66 mm Guide Rail (Buildout)
  • AnchorLoc 83 mm Guide Rail (End-Retention)

Standard Guide Rails provide immense strength with multiple size options used based on the curtain series needed.

STAX Guide Rails (buildout) provide the same strength as Standard Guide Rails with the addition of our STAX system. The STAX system allows you to build your shutter out from the storage unit or whatever surface your shutter is mounted to. This is very advantageous when you shutter needs to clear an object that would obstruct the path of the shutter curtain (an example of this is a drawer handle the shutter must clear).

AnchorLoc guide rails feature our end-retention system, providing an extreme level of strength for the shutter curtain, making it near-impossible to force the curtain out of the guide rails. This system consists on anchors that are attached to the curtain at regular intervals and fastened to the guide rails to prevent the curtain from potentially being forced out of the guide rails.

DISCOVER MORE FEATURES

Curtain

There are 9 curtain series available for TambourGuard shutters:

  • 400 Series - Roll formed aluminum with regular density foam filling (optional light slots)
    • 6 color options
  • 440 Series - Roll formed aluminum with ultra hard resin core (optional light slots)
    • 4 color options
  • 450 Series - Double wall extruded aluminum
    • 5 color options
  • 500 Series - Roll formed aluminum with regular density foam filling
    • 5 color options
  • 530 Series - Clear polycarbonate with aluminum connectors
    • Transparent (aluminum connectors available in all colors)
  • 540 Series - Roll formed aluminum with ultra hard resin core
    • 2 color options
  • 560 Series - Single wall extruded aluminum
    • 4 color options
  • 561 Series - Single wall extruded aluminum with small perforations
    • 4 color options

All curtain series are also available in any custom color desired.

DISCOVER MORE FEATURES

1
SECURE

  • Prevents identity theft by securing your files and records
  • Keeps your high dollar value items out of harms way behind a solid barrier
  • Adds extra protection to your office storage

2
PROTECT

  • Avoid harmful situations by protecting dangerous items in storage
  • Keep your equipment safe from theft having peace of mind it is secure
  • Keep potentially dangerous medicine products enclosed and protected

3
SHIELD

  • Provides a barrier for display merchanidse after hours
  • Leave products on display at all times by simply closing shutters when closed
  • Adds an aesthetic appeal as well as optimum protection

TAMBOURGUARD OPERATION AND MATERIALS

Operation

  • Minimal size, high-tech extruded aluminum housing
  • Simple operation, controlled by switch, remote wifi or app
  • Safe, long-lasting performance with the latest in motorized technologies
  • 2 part guide rails for a clean install and enduring servicability
  • Maximum energy conservation while creating blissful spaces

Materials

  • A variety of curtain styles and colors for that perfect look
  • Gorgeous selection of low maintenance materials
  • Commercial grade aluminum – Environmentally friendly material with positive effects during production and long term operation
  • High strength and durability means that your storage is secure and protected at all times

Specifications

Maximum Curtain Height:

Up to 192" (16ft)

Maximum Curtain Width:

Up to 228" (19ft)

Maximum Curtain Area:

Up to 284ft² (26.38 m²)

Material:

Extruded & Roll-formed Commercial-Grade Aluminum

Applications:

Residential, Commercial, Retail, Pharmacy, Education, Airports, Restaurant, Law Enforcement, Kiosks and more!

Available With End Retention:

https://pentagonshutters.com/wp-content/uploads/2021/06/AnchorLoc.png
https://pentagonshutters.com/wp-content/uploads/2021/08/AnchorLoc-e1728321039400.png

Mounting

Versatile in Design

TambourGuard storage shutters are fully customizable and are suitable for most prebuild or custom applications.

Static

Static

Bi-Lateral

Bi-Lateral

Mobile

Mobile

TAMBOURGUARD COMPONENTS AND PARTS

TAMBOURGUARD
TAMBOURGUARD
Roller Shutter Curtain
Pentagon Security Shutters’ Curtain Series sets a new standard in safeguarding your spaces with unparalleled versatility and durability. These advanced roller shutter curtains are engineered to provide robust protection against extreme weather, vandalism, and break-in attempts. Designed with end-retention systems for enhanced stability, these security shutter blinds ensure your property remains secure under the harshest conditions.

The Curtain Series offers a range of customizable shutter options by Pentagon Security Shutters, including DefendaGuard, TranquilGuard, and EntrexGuard, each offering various sizes, strengths, and designs. Features such as aluminum construction and high-tech coatings deliver exceptional performance and enhance aesthetic appeal. Some of the security shutter screens offered in this series include remote and Wi-Fi control for seamless integration with smart security systems, ensuring ease of use.

Whether protecting valuable assets or reducing energy costs, Pentagon Security Shutters delivers peace of mind through innovative security solutions. Protect your property today with our tailored shutters and withstand it all.
SEE Roller Shutter Curtain
BOTTOM BARS
Multiple Bottom Bar Sizes and Strengths For Security
SEE BOTTOM BARS
LOCKS
Multiple High-Security Locking Methods Available
SEE LOCKS
OPERATORS
Technologically Advanced Operation Methods
SEE OPERATORS
GUIDE RAILS
High Strength Guide Rails Provide Extensive Strength
SEE GUIDE RAILS
STAX (BUILDOUT)
2 Different STAX (Buildout) Depth Options
SEE STAX (BUILDOUT)
BOX HOUSINGS
4 Different Box Housing Sizes Available
SEE BOX HOUSINGS
